Product Overview
PM3008GSN-PD is 8-port 10/100/1000Mbps switch with 7 port PoE(Port1~7). Port8 is PD port, Support 95W input. Power supply support external power supply and PoE.
The electrical power and data transmission on the same cable can expand your network to the places where no power lines or outlets, where you can install devices such as APs, IP cameras, or IP phones etc.
Features
- Complies with IEEE802.3af/at Standard;
- Supports PoE Power up to 32W for each PoE port:
- 1*95W PD Port(Port8):
- Auto detect power device; will not burned non-standard PoE device or normal PoE switch;
- Supports port power supply prioritization, guarantee the continuous power supply of key nodes:
- Supports IEEE802.3 x full duplex flow control and Backpressure half duplex flow control;
- Line-speed forwarding, intelligent identification;
- Supports storage -and - forward for Data exchange;
- Iron case, no fan;
Product Specifications
Model | PM3008GSN-PD |
Standard | EEE802.3、 EEE802.3u、 EEE802.3x、 EEE802.3ab、 EEE802.3az、 |
PoE standard | IEEE802.3af/at |
Interface | 8*10/100/1000Mbps RJ45 port |
Key function | VLAN |
PoE port | 1-7 |
PD port input | 95W |
PoE Power Budget | 120W |
RJ45 PoE power supply | Mode A Anode1/2 Cathode3/6 |
PoE output-port | Max 32W |
Indicator | PWR、 LNK/ACT、 PoE |
Network media | 10BASE-T: UTP category 3, 4, 5 cable(≤100m) 100BASE-TX: UTP category 5, 5e cable(≤100m) 1000BASE-T: UTP category 5, 5e cable(≤100m) |
MAC Address Table | 4K, Automatic study, automatic updates |
jumbo frame | 9216 Bytes |
Packet buffer | 1.5M bit |
Transfer Mode | store-and-forward |
Packet forwarding rate | 11.9Mpps |
Bandwidth | 16Gbps |
Fan | Fanless |
Device Dimension | 138*108*50mm |
Machine weight | <1kg |
Input Voltage | DC: 55V |
Operating Temperature | -20°C ~ 70 °C |
Storage Temperature | -40 °C ~ 75 °C |
Operating Humidity | 10% ~ 90% non-condensing |
Storage Humidity | 5% ~ 90% non-condensing |
Surge Protection | Different mode±4KV common mode±6KV |
MTBF | >50000 hours |
Electrostatic standard | Contact 8KV, air 10KV |
Ordering information
Model | product information |
PM3008GSN-PD | 7-Port Gigabit+1GE(PD) Unmanaged PoE Switch |
