Product Overview
The PM3012GSFL V4 is a full Gigabit Unmanaged LCD 3rd Generation PoE Switch independently developed by UNIPOE, with 8*10/100/1000Mbps RJ45 and 2*1000Mbps Combo ports. Each RJ45 port supports MDI/MDIX auto-roll and wire-speed forwarding. Among them, 1-8 ports have PoE power supply and Switch control functions, bandwidth alarms, support IEEE802.3af/at standards, can be used as Power over Ethernet equipment, can automatically detect and identify powered equipment that meets the standard, and supply it through the network cable.
PM3012GSFL V4 support colorful LCD Display. The colorful LCD can display the PoE work status, accurate judgment port of load, can help customer and engineer timely discover and solve the network failure, improve work efficiency and quality.
Product Features
- IEEE 802.3at standard compliant IEEE 802.3af electrical receiving device (PD);
- Single port output power up to 30W;
- LCD display, real-time display of PoE status; The maximum viewing Angle is 180°;
- Automatic detection and identification of standard PoE power receiving devices, intelligent power supply, will not burn non-standard PoE power receiving devices or common devices;
- Port power priority is supported to ensure continuous power supply for key nodes on the network;
- IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control;
- Supports VLAN mode and CCTV mode. Users can enable or disable the function based on the application environment to improve network security and suppress network storms;
- Panel indicators and LCD display monitor working status and help fault analysis;
- Perfect security mechanism;
- Intelligent identification of wire speed forwarding;
- Data exchange adopts store-and-forward mode;
- Operating temperature: -5°C ~ 50 °C.
Product Specifications
| Model | PM3012GSFL V4 |
| Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Interface | 8*10/100/1000Mbps RJ45 PoE Ports
2*1000Mbps Combo Ports |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable(≤100m)
100BASE-TX: UTP category 5, 5e cable(≤100m)
1000BASE-T: UTP category 5e, 5 cable(≤100m)
1000BASE-X: MMF, SMF |
LCD Display Function
| LCD real-time display PoE working condition |
| MAC Address Table | 4K, Automatic study, automatic updates |
| Jumbo Frame | 9216 Bytes |
| Packet Buffer | 1.5M bit |
| Transfer Mode | store-and-forward |
| Bandwidth | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| PoE Power Supply | Mode A Anode1/2 Cathode3/6 |
| PoE Output | Max 30W |
| PoE Budget | 120W |
| Power Supply | 130W |
| Mains Input | AC 100~240V, 50/60Hz |
| Device Dimension | 280*180*44mm |
| Fan | 1 |
| Indicator | PWR, LNK/ACT, PoE |
| Operating Temperature | -5°C ~ 50 °C |
| Storage Temperature | -40 °C ~ 70 °C |
| Operating Humidity | 10% ~ 90% non-condensing |
| Storage Humidity) | 5% ~ 90% non-condensing |
| Machine Weight | <2.5kg |
| Surge Protection | Different mode±2KV, Common mode±4KV |
| MTBF | >50000 hour |
| Electrostatic Standard | Contact±6KV, Air±8KV |
LCD FeaturesThe LCD screen displays the status of PoE ports, including output power, overload, short circuit, light load, low voltage, overvoltage, and chip overtemperature of each port. This helps you know the PoE power supply status.
Not only such visible on the basis of three generations in the second generation increased color logo display, menu button, switch mode, bandwidth and early warning, PD type, PSE power fine-tuning and priority, PoE port Switch control, LCD, increased the LCD viewing angles, smart fan control, choice of language and the factory Settings, and other functions.Ordering Information| Model | Product Information |
| PM3012GSFL V4 | 8GE(PoE)+2G Combo LCD Display PoE Switch |
