Model NO.
PM124GS V2
Quantity:
Product Overview
PM124GS V2 is a Layer 2 Gigabit Unmanagement Switch that provides 24*10/100/1000 Mbit/s RJ45 ports. It uses the storage and forwarding technology and dynamic memory allocation to ensure efficient bandwidth allocation to each port. The Switch is easy to install and does not require configuration. It has the functions of one-click VLAN and CCTV. Users can choose to enable or disable the Switch according to
different application environments.



Product Features
  •  Complies with IEEE802.3, IEEE802.3u, IEEE802.3z IEEE802.3az, IEEE802.3x standards;
  •  RJ45 Supports automatic port flip (Auto MDI/MDIX);
  •  Supports IEEE802.3x full-duplex flow control and Backpressure half-duplex flow control;
  •  Perfect security mechanism;
  •  Intelligent recognition of wire speed forwarding;
  •  Data exchange adopts store-and-forward mode;
  •  Supports default, VLAN, and CCTV mode Switching;
  •  Operating temperature: 0°C ~ 40 °C.

Product Specifications
ModelPM124GS V2
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3x, IEEE802.3az , IEEE802.3ab
Interface24*10/100Mbps RJ45 ports
IndicatorPWR, LNK
Network Media10BASE-T: UTP category 3, 4, 5 cable (≤100m)
100BASE-TX: UTP category 5, 5e cable (≤100m)
1000BASE-T: UTP categoryy 5e, 6 cable (≤100m)
Transfer ModeStore-and-Forward
MAC Address Table8K, Automatic study, Automatic updates
Jumbo Frame9216Byte
Packet Buffer4.1M bit
Packet Forwarding Rate35.71Mpps
Bandwidth48Gbps
Device Dimension440*207*44mm
Power Supply12V/1.2A
Fanfanless
Green Energy SavingIEEE 802.3az
Mains Input100~240V AC, 50/60Hz
Operating Temperature0°C ~ 40 °C
Storage Temperature-40 °C ~ 70 °C
Operating Humidity10% ~ 90% RH non-condensing
Storage Humidity5% ~ 90% RH non-condensing
Surge ProtectionCommon mode ±2KV, Differential mode ±1KV
MTBF>50000 hour
Electrostatic StandardContact ±4KV, Air±6KV


Ordering information
ModelProduct Information
PM124GS V224GE Gigabit Switch
