Model NO.
PM3030GSM V2
Quantity:
Product Overview
The PM3030GSM V2 provides 24*10/100/1000Mbps RJ45 interface, 2G Combo interface and 2G SFP interface, 24 RJ45 interface all support PoE power supply, support static routing function, provide complete security policy, perfect QoS strategy and rich VLAN function, easy to manage and maintain, meet the enterprise, community, hotel, office network, campus network networking and access requirements


Product Features
  • Complies with IEEE802.3af/at Standard;
  • Support RJ45 Auto-MDI/MDIX;
  • Supports PoE Power up to 32W for each PoE port;
  • Auto detect power device;
  • Remote power and Data feeding up to 100m;
  • Flow Control for Full Duplex operation and back pressure for Half Duplex Operation;
  • Support Energy-Efficient Ethernet (EEE) function (IEEE802.3az)
  • Supports a complete lineup of L2 features, including 802.1Q tag VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and 802.3x Flow Control function;
  • Web, CLI (Console Port, Telnet, SSH), SNMP and RMON bring abundant management policies;
  • Support PD Alive function(the switch port is disconnected will automatically connected);


Product Specifications
Hardware Specification
ModelPM3030GSM V2
StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3z, IEEE 802.3x, IEEE 802.1X,
IEEE 802.1q , IEEE 802.1p, IEEE 802.1d , IEEE 802.1w, IEEE 802.3ad
IEEE802.3af, IEEE802.3at
Interface24*10/100/1000Mbps RJ45 Port (Auto Negotiation/Auto MDI/MDIX)
2*10/100/1000Mbps Combo ports
2* 100/1000Mbps SFP Slots
1 Console Port
IndicatorPWR, LNK/ACT, PoE
Network media10BASE-T: UTP category 3, 4, 5 cable(≤100m)
100BASE-TX: UTP category 5, 5e cable(≤100m)
1000BASE-T: UTP category 5e, 5 cable(≤100m)
100BASE-FX:MMF, SMF
1000BASE-X: MMF, SMF
MAC Address Table16K, Auto-learning, Auto-aging
jumbo frame12KBytes
Transfer ModeStore-and-forward
Packet Forward Speed41.66Mpps
Packet buffer12M
Switching Capacity56Gbps
Dimensions(L*W*H)440*207*44mm
Fan Quantity2
PoE PortPort1~24
PoE Power on RJ45Mode A  1/2(-), 3/6(+)
PoE Power OutputVoltage: 55V DC  Power: 32W(MAX)
PoE Power Budget250W370W
Power supply280W400W
Input Power Supply100~240V AC, 50/60Hz
Operating Temperature0°C ~ 40 °C
Storage Temperature-40 °C ~ 70 °C
Operating Humidity10% ~ 90% non-condensing
Storage Humidity5% ~ 90% non-condensing
Surge ProtectionCommon mode ±6KV  Differential mode ±4KV:
MTBF>50000 hour
Electrostatic standardContact 6KV, Air 8KV
Green energy savingSupport IEEE 802.3az


Software Specification
spanning  TreeIEEE  802.1D -Spanning Tree
IEEE  802.1w -Rapid SpanningTree
IEEE  802.1s -Multiple Spanning Tree
BPDU Guard
STP Root Guard
Loop Detection
VLANManagement VLAN
Private VLAN
Voice VLAN
Surveillance-VLAN
Q-in-Q (Double Tag)
802.1v Protocol VLAN
MAC-Based  VLAN
PortIEEE 802.3ad witch LACP(Dynamic)
Static Trunk
EEE
Jumbo Frame
Error-Disable
IGMP  SnoopingIGMP  Snooping v1/v2/v3
MLD Snooping v1/v2
MVR
QoS FeaturesHardware Queues
Class Of ServicePort Based
802.1p
CoS
DSCP
IP Precedence
TCP/UDP (IPv4/IPv6)
Rate LimitingIngress
Egress
Priority Queue SchedulingWRR
Strict Priority
DSCP & CS
IPv4 QoS (QCEs)
IPv6 QoS (QCEs)
SecurityPort Security
Port Isolation
IEEE802.1x AAA
ACLsL2+/L3/L4
IPv6 Support
Management Access List
Management ACL/Management ACE
IP Source Guard (IP-MAC-Port-VALN Binding)
IP Source Guard (IP-MAC-Port Binding)
Dynamic ARP Inspection
Storm Control
RADIUS/TACACS+
RADIUS Authentication (RFC2138)
DDoS Prevention
HTTPs and SSL (Secured Web)
SSH v1.5/v2.0 (Secured Telnet Session)
DHCP Snooping
DHCP Relay
ManagementSNMP (v1, v2c, v3)
RMON ( 1, 2, 3 & 9 groups)
Software Upgrade
Configuration Export/Import
DHCPClient
Option 82
Option 66
Option 67
Event/Error LogSyslog
Management Access FilteringConsole
SNMP
HTTP/HTTPS
Telnet
Port Mirroring
LLDP (IEEE802.1AB)
LLDP-MED
UDLD
DNS Client
Traceroute
Ping
Cable Test
DDMI
NTP/ SNTP (RFC2030)
IPv6 SupportDual IPv6/IPv4 stack
IPv6 Web/SSL
IPv6 SNTP (Simple Network Time Protocol)
IPv6 Telnet / SSH
IPv6 Ping/Traceroute
IPv6 TFTP
IPv6 RADIUS/TACACS+
IPv6 SNMP
ONVIFONVIF Deteciton
ONVIF Server(NLM)



Ordering information
Modelproduct information
PM3030GSM V224-Port Gigabit+2G Combo+2G SFP+1Console Managed PoE Switch(24-Port PoE, Support 802.3af/at Standard)
