10G 1 Optical 1 Electrical Fiber Optic Media Converter

Model NO.: PM301TSF V1

Quantity:

Product Description

Product Overview
PM301TSF V1 is a 10Gbps Fiber Optic Media Converter device developed by UNIPOE, this device can realize the conversion between 2 different transmission media, fiber and network cable, providing 1*100M/1G/2.5G/5G/10Gbps adaptive RJ45 port and 1*10Gbps SFP+ fiber module slot, which can convert the short distance 10Gbase-TX twisted pair electrical signal and long distance 10Gbase-FX optical signal to each other users can choose different types of optical modules according to their needs. The product can be widely used in security monitoring, wireless networking, fiber optic access and other application scenarios.

Product Features

Compatible with IEEE802.3u, IEEE802.3ab, IEEE802.3bz, IEEE802.3an, IEEE802.3ae, IEEE802.3x Ethernet standards;
Provide a 100M/1G/2.5G/5G/10Gbps adaptive RJ45 port and a 10Gbps SFP+ fiber module slot, stable and smooth data transmission without loss;
Network port supports fully automatic cross recognition, full/half duplex MDI/MDI-X adaptive;
Support 850, 1310, 1550nm and ITU-T specified CWDM/DWDM wavelengths;
Panel indicators monitor operating status and help with fault analysis;
Plug-and-play, no configuration required, hot-plugging support;
Working temperature: 0℃~40℃.

Product Specifications

Model	PM301TSF V1
Interface	1100M/1G/2.5G/5G/10Gbps RJ45 Port 110Gbps SFP slot
Protocol Standards	IEEE802.3u 100BASE-TX IEEE802.3ab 1000BASE-T IEEE802.3bz 2.5G/5GBASE-T IEEE802.3an 10GBASE-T IEEE802.3ae 10Gbps Ethernet IEEE802.3x full-duplex flow control (Copper Port)
Network Cables	10G/5G/2.5G/1G/100M BASE-T: 10G--Cat. 6A and above unshielded category twisted pair 5G--Cat. 6 and above unshielded category twisted pair 1G/2.5G--Cat. 5e and above unshielded category twisted pair 100M-- Cat. 5 and above unshielded category twisted pair Cat. 5/5e/6/6A UTP cable (100 meters, max.) EIA/TIA-568 100-ohm STP (100 meters, max.)
Indicator Light	PWR (Green), LNK/ACT (Green),SD (Green)
Input Voltage	12V/1A, DC Adapter
Appearance Size（LWH）	93.57026mm, Black
Operating Temperature	0℃~40℃
Storage Temperature	-40℃~80℃
Operating Humidity	10% ~ 90% non-condensing
Storage Humidity	5% ~ 90% non-condensing
Surge Protection	Differential mode ±2KV, Common mode ±4KV
Electrostatic Standard	Contact ±6KV, Air ±8KV
MTBF	>100000 hours
